Size S
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XXS | XS | S | M | L | XL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,841 | $3,841 | $3,841 | $3,841 | $3,841 | $3,841 |
| Frame kit (g) | 2150 | 2150 | 2150 | 2150 | 2150 | 2150 |
| Stack | 480 mm | 500 mm | 520 mm | 541 mm | 561 mm | 580 mm |
| Reach | 372 mm | 383 mm | 395 mm | 407 mm | 419 mm | 431 mm |
| Stack / Reach | 1.29 | 1.30 | 1.32 | 1.33 | 1.34 | 1.35 |
| Head tube angle | 71° | 71.5° | 72° | 72° | 72.5° | 72.5° |
| Seat tube angle (effective) | 74° | 74° | 74° | 74° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 507 mm | 519 mm | 544 mm | 562 mm | 580 mm | 598 mm |
| Head tube length | 77 mm | 96 mm | 117 mm | 138 mm | 161 mm | 181 mm |
| Seat tube length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Bottom bracket drop | 75 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Bottom bracket height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Chainstay | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Front center | 568.9 mm | 583.8 mm | 598 mm | 615.9 mm | 629.9 mm | 647.8 mm |
| Wheelbase | 967 mm | 982 mm | 997 mm | 1015 mm | 1030 mm | 1048 mm |
| Fork rake (offset) | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Fork axle to crown | 371 mm | 371 mm | 371 mm | 371 mm | 371 mm | 371 mm |
| Trail | — | — | — | — | — | — |
| Standover | 738 mm | 758 mm | 781 mm | 800 mm | 823 mm | 842 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
