Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $2,165 | $2,165 | $2,165 | $2,165 | $2,165 | $2,165 |
| Frame kit (g) | 1420 | 1420 | 1420 | 1420 | 1420 | 1420 |
| Stack | 507 mm | 521 mm | 535 mm | 550 mm | 564 mm | 593 mm |
| Reach | 365 mm | 374 mm | 383 mm | 391 mm | 400 mm | 407 mm |
| Stack / Reach | 1.39 | 1.39 | 1.40 | 1.41 | 1.41 | 1.46 |
| Head tube angle | 70.8° | 71.3° | 72.2° | 72.3° | 72.3° | 73.2° |
| Seat tube angle (effective) | 74.9° | 74.9° | 74° | 73.5° | 73.1° | 73.1° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 502 mm | 514 mm | 536 mm | 554 mm | 571 mm | 587 mm |
| Head tube length | 107 mm | 120 mm | 130 mm | 145 mm | 160 mm | 187 mm |
| Seat tube length | 430 mm | 460 mm | 480 mm | 510 mm | 530 mm | 560 mm |
| Bottom bracket drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Bottom bracket height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Chainstay | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Front center | 572.9 mm | 581.8 mm | 580.9 mm | 592.8 mm | 606.7 mm | 613.6 mm |
| Wheelbase | 972 mm | 981 mm | 980 mm | 992 mm | 1006 mm | 1013 mm |
| Fork rake (offset) | 49 mm | 49 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | 369 mm | 369 mm | 369 mm | 369 mm | 369 mm | 369 mm |
| Trail | — | — | — | — | — | — |
| Standover | 729 mm | 752 mm | 769 mm | 791 mm | 808 mm | 837 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
