Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,014 | $3,014 | $3,014 | $3,014 | $3,014 | $3,014 |
| Frame kit (g) | 1580 | 1580 | 1580 | 1580 | 1580 | 1580 |
| Stack | 531 mm | 544 mm | 561 mm | 578 mm | 598 mm | 619 mm |
| Reach | 367 mm | 375 mm | 383 mm | 391 mm | 399 mm | 407 mm |
| Stack / Reach | 1.45 | 1.45 | 1.47 | 1.48 | 1.50 | 1.52 |
| Head tube angle | 70.5° | 70.7° | 71.2° | 71.5° | 71.5° | 71.5° |
| Seat tube angle (effective) | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 524 mm | 536 mm | 549 mm | 562 mm | 576 mm | 590 mm |
| Head tube length | 100 mm | 113 mm | 130 mm | 147 mm | 170 mm | 193 mm |
| Seat tube length | 440 mm | 460 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Bottom bracket drop | 78 mm | 78 mm | 76 mm | 76 mm | 74 mm | 74 mm |
| Bottom bracket height | 283 mm | 283 mm | 285 mm | 285 mm | 287 mm | 287 mm |
| Chainstay | 423 mm | 423 mm | 425 mm | 425 mm | 427 mm | 427 mm |
| Front center | 589.4 mm | 600.3 mm | 606.6 mm | 617.5 mm | 632.8 mm | 647.7 mm |
| Wheelbase | 1000 mm | 1011 mm | 1020 mm | 1031 mm | 1049 mm | 1064 mm |
| Fork rake (offset) | 54 mm | 54 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork axle to crown | 398 mm | 398 mm | 398 mm | 398 mm | 398 mm | 398 mm |
| Trail | — | — | — | — | — | — |
| Standover | 751 mm | 768 mm | 788 mm | 811 mm | 839 mm | 865 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
