Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Price (CAD) | $2,713 | $2,713 | $2,713 | $2,713 | $2,713 |
| Frame kit (g) | 1330 | 1330 | 1330 | 1330 | 1330 |
| Stack | 510 mm | 517.4 mm | 520.1 mm | 561.7 mm | 586.5 mm |
| Reach | 367 mm | 371 mm | 382 mm | 390 mm | 400 mm |
| Stack / Reach | 1.39 | 1.40 | 1.36 | 1.44 | 1.47 |
| Head tube angle | 71° | 71.2° | 72° | 73° | 73° |
| Seat tube angle (effective) | 75.3° | 74.2° | 74° | 74° | 73.3° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 500.8 mm | 517.4 mm | 531.1 mm | 551.1 mm | 576.0 mm |
| Head tube length | 112 mm | 119 mm | 119 mm | 159 mm | 185 mm |
| Seat tube length | 410 mm | 440 mm | 470 mm | 510 mm | 550 mm |
| Bottom bracket drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Bottom bracket height | 273 mm | 273 mm | 271 mm | 273 mm | 273 mm |
| Chainstay | 408 mm | 408 mm | 403 mm | 408 mm | 408 mm |
| Front center | 570.9 mm | 575.5 mm | 580.2 mm | 586.9 mm | 609.4 mm |
| Wheelbase | 969.1 mm | 973.8 mm | 973.4 mm | 985.2 mm | 1007.9 mm |
| Fork rake (offset) | 45 mm | 45 mm | 45 mm | 42 mm | 42 mm |
| Fork axle to crown | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm |
| Trail | — | — | — | — | — |
| Standover | 717 mm | 740 mm | 763 mm | 800 mm | 836 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
