Size 18.5in(29)
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
13.5in(27.5) | 15.5in(27.5) | 17.5in(29) | 18.5in(29) | 19.5in(29) | 21.5in(29) | 23in(XXL,29) | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $1,096 | $1,096 | $1,096 | $1,096 | $1,096 | $1,096 | $1,096 |
| Frame kit (g) | 1930 | 1930 | 1930 | 1930 | 1930 | 1930 | 1930 |
| Stack | 565 mm | 574 mm | 598 mm | 598 mm | 608 mm | 627 mm | 627 mm |
| Reach | 376 mm | 385 mm | 418 mm | 434 mm | 451 mm | 466 mm | 480 mm |
| Stack / Reach | 1.50 | 1.49 | 1.43 | 1.38 | 1.35 | 1.34 | 1.31 |
| Head tube angle | 69.3° | 69.3° | 69.5° | 69.5° | 69.5° | 69.5° | 69.5° |
| Seat tube angle (effective) | 73.5° | 73.5° | 73° | 73° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 544 mm | 555 mm | 601 mm | 617 mm | 637 mm | 658 mm | 672 mm |
| Head tube length | 90 mm | 90 mm | 90 mm | 90 mm | 100 mm | 120 mm | 120 mm |
| Seat tube length | 343 mm | 368 mm | 419 mm | 444 mm | 470 mm | 521 mm | 559 mm |
| Bottom bracket drop | 58 mm | 48 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Bottom bracket height | 292 mm | 302 mm | 311 mm | 310 mm | 310 mm | 310 mm | 311 mm |
| Chainstay | 425 mm | 425 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Front center | 617.7 mm | 632.5 mm | 677.3 mm | 693.3 mm | 713.2 mm | 735.1 mm | 749.1 mm |
| Wheelbase | 1036 mm | 1053 mm | 1109 mm | 1125 mm | 1145 mm | 1167 mm | 1181 mm |
| Fork rake (offset) | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | 88 mm | 88 mm | 94 mm | 94 mm | 94 mm | 94 mm | 94 mm |
| Standover | 698 mm | 724 mm | 748 mm | 757 mm | 757 mm | 768 mm | 804 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
