Size 3 High
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
1 High | 1 Low | 2 High | 2 Low | 3 High | 3 Low | 4 High | 4 Low | 5 High | 5 Low | |
|---|---|---|---|---|---|---|---|---|---|---|
| Price (CAD) | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 |
| Frame kit (g) | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 |
| Stack | 566 mm | 570 mm | 599 mm | 603 mm | 604 mm | 607 mm | 608 mm | 612 mm | 626 mm | 630 mm |
| Reach | 422 mm | 417 mm | 452 mm | 447 mm | 467 mm | 462 mm | 482 mm | 477 mm | 512 mm | 507 mm |
| Stack / Reach | 1.34 | 1.37 | 1.32 | 1.35 | 1.29 | 1.31 | 1.26 | 1.28 | 1.22 | 1.24 |
| Head tube angle | 65.9° | 65.5° | 65.9° | 65.5° | 65.9° | 65.5° | 65.9° | 65.5° | 65.9° | 65.5° |
| Seat tube angle (effective) | 76.5° | 76° | 77.3° | 76.9° | 76.6° | 76.2° | 76.3° | 75.9° | 75.6° | 75.2° |
| Seat tube angle (actual) | — | — | — | — | — | — | — | — | — | — |
| Top tube (effective) | 558 mm | 559 mm | 587 mm | 588 mm | 611 mm | 612 mm | 630 mm | 631 mm | 672 mm | 673 mm |
| Head tube length | 105 mm | 105 mm | 105 mm | 105 mm | 110 mm | 110 mm | 115 mm | 115 mm | 135 mm | 135 mm |
| Seat tube length | 360 mm | 360 mm | 410 mm | 410 mm | 420 mm | 420 mm | 435 mm | 435 mm | 470 mm | 470 mm |
| Bottom bracket drop | 10 mm | 16 mm | 26 mm | 32 mm | 26 mm | 32 mm | 26 mm | 32 mm | 26 mm | 32 mm |
| Bottom bracket height | 351 mm | 345 mm | 354 mm | 348 mm | 354 mm | 348 mm | 354 mm | 348 mm | 354 mm | 348 mm |
| Chainstay | 434 mm | 435 mm | 434 mm | 435 mm | 439 mm | 440 mm | 439 mm | 440 mm | 444 mm | 445 mm |
| Front center | 717 mm | 717 mm | 755 mm | 755 mm | 772 mm | 772 mm | 789 mm | 789 mm | 827 mm | 827 mm |
| Wheelbase | 1150 mm | 1151 mm | 1188 mm | 1188 mm | 1210 mm | 1210 mm | 1227 mm | 1227 mm | 1270 mm | 1271 mm |
| Fork rake (offset) | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | — | — | — | — | — | — | — | — | — | — |
| Trail | 111 mm | 115 mm | 121 mm | 125 mm | 121 mm | 125 mm | 121 mm | 125 mm | 121 mm | 125 mm |
| Standover | 705 mm | 700 mm | 755 mm | 750 mm | 757 mm | 752 mm | 758 mm | 753 mm | 763 mm | 758 mm |
| Pad / effective stack | — | — | — | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — | — | — | — |
