Trek
A cross-country mountain bike frameset in 5 sizes, from S to XL.
Frameset price, size ML
$6,028
aggressive · neutral handling
From Trek’s own numbers for the ML, not marketing copy.
aggressive · neutral handling
From your saved height and inseam, not a height range.
Every size, straight from Trek’s chart. Blanks are numbers Trek doesn’t publish; we don’t fill them in.
| Measurement | |||||
|---|---|---|---|---|---|
| Stack (mm) | 590 | 590 | 590 | 599 | 622 |
| Reach (mm) | 410 | 435 | 450 | 465 | 500 |
| Stack / Reach | 1.44 | 1.36 | 1.31 | 1.29 | 1.24 |
| Head tube angle (°) | 67.5 | 67.5 | 67.5 | 67.5 | 67.5 |
| Seat tube angle (effective) (°) | 74.5 | 74.5 | 74.5 | 74.5 | 74.5 |
| Top tube (effective) (mm) | 571 | 592 | 605 | 622 | 663 |
| Chainstay (mm) | 435 | 435 | 435 | 435 | 435 |
| Wheelbase (mm) | 1113 | 1138 | 1153 | 1172 | 1217 |
| Trail (mm) | 109 | 109 | 109 | 109 | 109 |
| Standover (mm) | 760 | 772 | 772 | 772 | 772 |
Trek’s geometry chart, read Jul 21, 2026.
| Size | Frameset weight(g) | Price(CAD) |
|---|---|---|
| S | 1950 | $6,028 |
| M | 1950 | $6,028 |
| ML | 1950 | $6,028 |
| L | 1950 | $6,028 |
| XL | 1950 | $6,028 |
Trek hasn’t published frame bolt torques we can point to yet
