Size 18.5in(MX)
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
15.5in(27.5) | 17.5in(MX) | 18.5in(MX) | 19.5in(MX) | 21.5in(MX) | |
|---|---|---|---|---|---|
| Price (CAD) | $5,891 | $5,891 | $5,891 | $5,891 | $5,891 |
| Frame kit (g) | 4600 | 4600 | 4600 | 4600 | 4600 |
| Stack | 588 mm | 623 mm | 632 mm | 641 mm | 659 mm |
| Reach | 430 mm | 448 mm | 468 mm | 488 mm | 513 mm |
| Stack / Reach | 1.37 | 1.39 | 1.35 | 1.31 | 1.28 |
| Head tube angle | 63.5° | 63.3° | 63.3° | 63.3° | 63.3° |
| Seat tube angle (effective) | 78.1° | 77.8° | 77.3° | 77.1° | 76.7° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 548 mm | 578 mm | 605 mm | 628 mm | 658 mm |
| Head tube length | 100 mm | 100 mm | 110 mm | 120 mm | 140 mm |
| Seat tube length | 390 mm | 400 mm | 420 mm | 435 mm | 470 mm |
| Bottom bracket drop | 10 mm | 27 mm | 27 mm | 27 mm | 27 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 429 mm | 429 mm | 434 mm | 434 mm | 439 mm |
| Front center | 766.2 mm | 796.3 mm | 820.3 mm | 845.3 mm | 874.2 mm |
| Wheelbase | 1195 mm | 1224 mm | 1253 mm | 1278 mm | 1312 mm |
| Fork rake (offset) | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | — | — | — | — | — |
| Trail | 132 mm | 143 mm | 143 mm | 143 mm | 143 mm |
| Standover | 727 mm | 766 mm | 766 mm | 767 mm | 768 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
