Size 2 High
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
1 High | 1 Low | 2 High | 2 Low | 3 High | 3 Low | |
|---|---|---|---|---|---|---|
| Price (CAD) | $4,658 | $4,658 | $4,658 | $4,658 | $4,658 | $4,658 |
| Frame kit (g) | 5700 | 5700 | 5700 | 5700 | 5700 | 5700 |
| Stack | 634 mm | 639 mm | 634 mm | 639 mm | 634 mm | 639 mm |
| Reach | 447 mm | 440 mm | 472 mm | 465 mm | 499 mm | 493 mm |
| Stack / Reach | 1.42 | 1.45 | 1.34 | 1.37 | 1.27 | 1.30 |
| Head tube angle | 63.6° | 63° | 63.6° | 63° | 63.6° | 63° |
| Seat tube angle (effective) | 77.1° | 76.5° | 77.1° | 76.5° | 77.1° | 76.5° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 586 mm | 587 mm | 617 mm | 618 mm | 652 mm | 653 mm |
| Head tube length | 117 mm | 117 mm | 117 mm | 117 mm | 117 mm | 117 mm |
| Seat tube length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Bottom bracket drop | 12 mm | 21 mm | 12 mm | 21 mm | 12 mm | 21 mm |
| Bottom bracket height | 359 mm | 350 mm | 359 mm | 350 mm | 359 mm | 350 mm |
| Chainstay | 435 mm | 439 mm | 441 mm | 445 mm | 448 mm | 452 mm |
| Front center | 808.3 mm | 807.8 mm | 833.2 mm | 832.8 mm | 861.2 mm | 860.7 mm |
| Wheelbase | 1243 mm | 1246 mm | 1274 mm | 1277 mm | 1309 mm | 1312 mm |
| Fork rake (offset) | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 131 mm | 136 mm | 131 mm | 136 mm | 132 mm | 136 mm |
| Standover | 755 mm | 747 mm | 759 mm | 751 mm | 757 mm | 749 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
