Size 18.5in(29)
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
14.5in(27.5) | 15.5in(27.5) | 17.5in(29) | 18.5in(29) | 19.5in(29) | 21.5in(29) | 23in(XXL,29) | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $753 | $753 | $753 | $753 | $753 | $753 | $753 |
| Frame kit (g) | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 |
| Stack | 563 mm | 572 mm | 609 mm | 614 mm | 618 mm | 637 mm | 651 mm |
| Reach | 390 mm | 415 mm | 440 mm | 455 mm | 470 mm | 495 mm | 520 mm |
| Stack / Reach | 1.44 | 1.38 | 1.38 | 1.35 | 1.31 | 1.29 | 1.25 |
| Head tube angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
| Seat tube angle (effective) | 74° | 74° | 74° | 74° | 74° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 551 mm | 579 mm | 615 mm | 631 mm | 647 mm | 678 mm | 707 mm |
| Head tube length | 90 mm | 100 mm | 105 mm | 110 mm | 115 mm | 135 mm | 150 mm |
| Seat tube length | 340 mm | 370 mm | 420 mm | 435 mm | 450 mm | 500 mm | 540 mm |
| Bottom bracket drop | 45 mm | 45 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Bottom bracket height | 313 mm | 313 mm | 308 mm | 308 mm | 308 mm | 308 mm | 308 mm |
| Chainstay | 433 mm | 433 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Front center | 662.9 mm | 691.8 mm | 731.6 mm | 748.5 mm | 765.5 mm | 798.4 mm | 829.3 mm |
| Wheelbase | 1092 mm | 1121 mm | 1163 mm | 1180 mm | 1197 mm | 1230 mm | 1261 mm |
| Fork rake (offset) | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm |
| Standover | 658 mm | 692 mm | 747 mm | 759 mm | 771 mm | 791 mm | 816 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
