Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
44 | 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $1,300 | $1,300 | $1,300 | $1,300 | $1,300 | $1,300 | $1,300 |
| Frame kit (g) | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 |
| Stack | 510 mm | 540 mm | 561 mm | 575 mm | 591 mm | 611 mm | 646 mm |
| Reach | 360 mm | 368 mm | 371 mm | 374 mm | 377 mm | 380 mm | 385 mm |
| Stack / Reach | 1.42 | 1.47 | 1.51 | 1.54 | 1.57 | 1.61 | 1.68 |
| Head tube angle | 70.3° | 70.8° | 71.3° | 71.3° | 71.9° | 72° | 72.1° |
| Seat tube angle (effective) | 74.6° | 74.6° | 74.2° | 73.7° | 73.3° | 73° | 72.7° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 507 mm | 516 mm | 530 mm | 542 mm | 554 mm | 567 mm | 586 mm |
| Head tube length | 95 mm | 123 mm | 145 mm | 160 mm | 175 mm | 195 mm | 235 mm |
| Seat tube length | 390 mm | 440 mm | 475 mm | 500 mm | 525 mm | 548 mm | 576 mm |
| Bottom bracket drop | 80 mm | 80 mm | 80 mm | 80 mm | 78 mm | 78 mm | 75 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 420 mm | 425 mm | 420 mm | 420 mm | 420 mm | 425 mm | 425 mm |
| Front center | 576.3 mm | 589.1 mm | 596.1 mm | 603 mm | 610.3 mm | 609.2 mm | 624.2 mm |
| Wheelbase | 983 mm | 1001 mm | 1003 mm | 1010 mm | 1018 mm | 1022 mm | 1038 mm |
| Fork rake (offset) | 53 mm | 53 mm | 53 mm | 53 mm | 48 mm | 48 mm | 48 mm |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | 66 mm | 66 mm | 59 mm | 59 mm | 61 mm | 60 mm | 63 mm |
| Standover | 657 mm | 717 mm | 735 mm | 754 mm | 776 mm | 796 mm | 842 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
