Size 3
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
1 | 2 | 3 | 4 | 5 | 6 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,562 | $3,562 | $3,562 | $3,562 | $3,562 | $3,562 |
| Frame kit (g) | 1921 | 1921 | 1921 | 1921 | 1921 | 1921 |
| Stack | 535 mm | 556 mm | 579 mm | 601 mm | 620 mm | 640 mm |
| Reach | 380 mm | 386 mm | 391 mm | 397 mm | 402 mm | 408 mm |
| Stack / Reach | 1.41 | 1.44 | 1.48 | 1.51 | 1.54 | 1.57 |
| Head tube angle | 71° | 71.4° | 71.6° | 72° | 72.1° | 72.4° |
| Seat tube angle (effective) | 72.7° | 73° | 72.8° | 72.8° | 72.8° | 72.8° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 536 mm | 547 mm | 566 mm | 578 mm | 589 mm | 601 mm |
| Head tube length | 86 mm | 106 mm | 130 mm | 151 mm | 171 mm | 191 mm |
| Seat tube length | 445 mm | 480 mm | 505 mm | 530 mm | 550 mm | 575 mm |
| Bottom bracket drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Front center | 594.6 mm | 603.6 mm | 615.5 mm | 623.4 mm | 633.3 mm | 643.3 mm |
| Wheelbase | 1013 mm | 1022 mm | 1034 mm | 1042 mm | 1052 mm | 1062 mm |
| Fork rake (offset) | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 71 mm | 68 mm | 68 mm | 64 mm | 64 mm | 62 mm |
| Standover | 746 mm | 772 mm | 799 mm | 813 mm | 837 mm | 861 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
