Size 3
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
1 | 2 | 3 | 4 | 5 | 6 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $1,438 | $1,438 | $1,438 | $1,438 | $1,438 | $1,438 |
| Frame kit (g) | 2403 | 2403 | 2403 | 2403 | 2403 | 2403 |
| Stack | 545 mm | 566 mm | 589 mm | 611 mm | 630 mm | 650 mm |
| Reach | 380 mm | 385 mm | 391 mm | 397 mm | 402 mm | 408 mm |
| Stack / Reach | 1.43 | 1.47 | 1.51 | 1.54 | 1.57 | 1.59 |
| Head tube angle | 71.2° | 71.6° | 71.8° | 72.2° | 72.3° | 72.6° |
| Seat tube angle (effective) | 74.1° | 73.7° | 73.2° | 72.8° | 72.5° | 72.1° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 536 mm | 548 mm | 568 mm | 580 mm | 592 mm | 604 mm |
| Head tube length | 96 mm | 117 mm | 140 mm | 162 mm | 181 mm | 201 mm |
| Seat tube length | 445 mm | 480 mm | 505 mm | 530 mm | 550 mm | 575 mm |
| Bottom bracket drop | 78 mm | 78 mm | 76 mm | 76 mm | 74 mm | 74 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Front center | 602.1 mm | 610.1 mm | 617.4 mm | 624.3 mm | 633.7 mm | 645.6 mm |
| Wheelbase | 1025 mm | 1033 mm | 1041 mm | 1048 mm | 1058 mm | 1070 mm |
| Fork rake (offset) | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 74 mm | 71 mm | 70 mm | 67 mm | 66 mm | 65 mm |
| Standover | 735 mm | 765 mm | 789 mm | 809 mm | 829 mm | 859 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
