Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | ML | L | XL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $6,028 | $6,028 | $6,028 | $6,028 | $6,028 | $6,028 |
| Frame kit (g) | 1561 | 1561 | 1561 | 1561 | 1561 | 1561 |
| Stack | 525 mm | 540 mm | 560 mm | 584 mm | 608 mm | 633 mm |
| Reach | 380 mm | 385 mm | 392 mm | 399 mm | 404 mm | 409 mm |
| Stack / Reach | 1.38 | 1.40 | 1.43 | 1.46 | 1.50 | 1.55 |
| Head tube angle | 71° | 71.3° | 71.5° | 71.7° | 72° | 72.4° |
| Seat tube angle (effective) | 73.9° | 73.9° | 73.7° | 73.5° | 73.6° | 73.7° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 532 mm | 540 mm | 555 mm | 570 mm | 581 mm | 592 mm |
| Head tube length | 91 mm | 106 mm | 126 mm | 150 mm | 174 mm | 199 mm |
| Seat tube length | 373 mm | 414 mm | 455 mm | 500 mm | 537 mm | 583 mm |
| Bottom bracket drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Front center | 590 mm | 598 mm | 608.9 mm | 621.7 mm | 631.7 mm | 640.6 mm |
| Wheelbase | 1003 mm | 1011 mm | 1022 mm | 1035 mm | 1045 mm | 1054 mm |
| Fork rake (offset) | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | 72 mm | 70 mm | 68 mm | 67 mm | 65 mm | 62 mm |
| Standover | 718 mm | 747 mm | 782 mm | 816 mm | 851 mm | 886 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
