Size 3
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
1 | 2 | 3 | 4 | 5 | |
|---|---|---|---|---|---|
| Price (CAD) | $5,069 | $5,069 | $5,069 | $5,069 | $5,069 |
| Frame kit (g) | 2400 | 2400 | 2400 | 2400 | 2400 |
| Stack | 580 mm | 617 mm | 634 mm | 652 mm | 673 mm |
| Reach | 395 mm | 407 mm | 417 mm | 427 mm | 435 mm |
| Stack / Reach | 1.47 | 1.52 | 1.52 | 1.53 | 1.55 |
| Head tube angle | 68.8° | 69° | 69.4° | 69.5° | 69.4° |
| Seat tube angle (effective) | 74.6° | 74.2° | 73.7° | 73° | 72.6° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 564 mm | 589 mm | 597 mm | 613 mm | 628 mm |
| Head tube length | 94 mm | 133 mm | 149 mm | 170 mm | 193 mm |
| Seat tube length | 440 mm | 470 mm | 520 mm | 540 mm | 560 mm |
| Bottom bracket drop | 70 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Front center | 648.4 mm | 672.2 mm | 684.2 mm | 701.6 mm | 716.5 mm |
| Wheelbase | 1081 mm | 1105 mm | 1117 mm | 1135 mm | 1150 mm |
| Fork rake (offset) | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Fork axle to crown | — | — | — | — | — |
| Trail | 92 mm | 91 mm | 88 mm | 88 mm | 88 mm |
| Standover | 772 mm | 804 mm | 838 mm | 846 mm | 852 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
