Size S
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XXS | XS | S | M | L | XL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $7,499 | $7,499 | $7,499 | $7,499 | $7,499 | $7,499 |
| Frame kit (g) | 1300 | 1300 | 1300 | 1300 | 1300 | 1300 |
| Stack | 515 mm | 532 mm | 549 mm | 567 mm | 584 mm | 601 mm |
| Reach | 372 mm | 377 mm | 382 mm | 389 mm | 392 mm | 397 mm |
| Stack / Reach | 1.38 | 1.41 | 1.44 | 1.46 | 1.49 | 1.51 |
| Head tube angle | 71.5° | 71.5° | 71.5° | 72° | 73° | 73° |
| Seat tube angle (effective) | 73° | 73° | 73° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 529 mm | 540 mm | 549 mm | 560 mm | 574 mm | 584 mm |
| Head tube length | 120 mm | 138 mm | 154 mm | 167 mm | 185 mm | 203 mm |
| Seat tube length | — | — | — | — | — | — |
| Bottom bracket drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Front center | 579 mm | 590 mm | 595 mm | 604 mm | 600 mm | 609 mm |
| Wheelbase | 980 mm | 991 mm | 996 mm | 1005 mm | 1001 mm | 1011 mm |
| Fork rake (offset) | 50 mm | 50 mm | 50 mm | 50 mm | 43 mm | 43 mm |
| Fork axle to crown | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm |
| Trail | 62 mm | 62 mm | 62 mm | 59 mm | 60 mm | 60 mm |
| Standover | — | — | — | — | — | — |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
