Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Price (CAD) | $5,999 | $5,999 | $5,999 | $5,999 | $5,999 |
| Frame kit (g) | 1480 | 1480 | 1480 | 1480 | 1480 |
| Stack | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Reach | 362 mm | 368 mm | 378 mm | 386 mm | 391 mm |
| Stack / Reach | 1.49 | 1.52 | 1.53 | 1.55 | 1.59 |
| Head tube angle | 70.5° | 71.5° | 72.5° | 72.5° | 72.5° |
| Seat tube angle (effective) | 73.7° | 73° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 530 mm | 544 mm | 559 mm | 575 mm | 591 mm |
| Head tube length | 134 mm | 150 mm | 168 mm | 188 mm | 208 mm |
| Seat tube length | — | — | — | — | — |
| Bottom bracket drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Front center | 589 mm | 591 mm | 598 mm | 613 mm | 618 mm |
| Wheelbase | 1004 mm | 1006 mm | 1012 mm | 1026 mm | 1033 mm |
| Fork rake (offset) | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Fork axle to crown | 383 mm | 383 mm | 383 mm | 383 mm | 383 mm |
| Trail | 69 mm | 63 mm | 56 mm | 56 mm | 56 mm |
| Standover | 762 mm | 788 mm | 812 mm | 828 mm | 857 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
