Size S
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | |
|---|---|---|---|---|
| Price (CAD) | $4,499 | $4,499 | $4,499 | $4,499 |
| Frame kit (g) | 1440 | 1440 | 1440 | 1440 |
| Stack | 526 mm | 543 mm | 562 mm | 581 mm |
| Reach | 374 mm | 373 mm | 383 mm | 392 mm |
| Stack / Reach | 1.41 | 1.46 | 1.47 | 1.48 |
| Head tube angle | 71.5° | 72° | 73° | 73° |
| Seat tube angle (effective) | 73.7° | 73° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 530 mm | 540 mm | 555 mm | 570 mm |
| Head tube length | 133 mm | 149 mm | 166 mm | 186 mm |
| Seat tube length | — | — | — | — |
| Bottom bracket drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Bottom bracket height | — | — | — | — |
| Chainstay | 404 mm | 404 mm | 404 mm | 404 mm |
| Front center | 578 mm | 578 mm | 584 mm | 599 mm |
| Wheelbase | 973 mm | 973 mm | 979 mm | 994 mm |
| Fork rake (offset) | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | 368 mm | 368 mm | 368 mm | 368 mm |
| Trail | 68 mm | 64 mm | 58 mm | 58 mm |
| Standover | — | — | — | — |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
