Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 PC | 50 PC | 52 PC | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $2,999 | $2,999 | $2,999 | $2,999 | $2,999 | $2,999 | $2,999 |
| Frame kit (g) | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| Stack | 523 mm | 533 mm | 543 mm | 558 mm | 577 mm | 593 mm | 605 mm |
| Reach | 370 mm | 371 mm | 375.5 mm | 383 mm | 390 mm | 399 mm | 411 mm |
| Stack / Reach | 1.41 | 1.44 | 1.45 | 1.46 | 1.48 | 1.49 | 1.47 |
| Head tube angle | 71.3° | 71.5° | 71.5° | 72.3° | 73.3° | 73.3° | 73.3° |
| Seat tube angle (effective) | 76° | 75° | 74.5° | 74° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 500 mm | 514 mm | 526 mm | 543 mm | 561 mm | 575 mm | 590 mm |
| Head tube length | 98 mm | 108 mm | 118 mm | 131 mm | 148 mm | 164 mm | 177 mm |
| Seat tube length | 477.5 mm | 495.5 mm | 507.5 mm | 527.5 mm | 547.5 mm | 567.5 mm | 582.5 mm |
| Bottom bracket drop | — | — | — | — | — | — | — |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Front center | — | — | — | — | — | — | — |
| Wheelbase | 982 mm | 985 mm | 992 mm | 998 mm | 1001 mm | 1015 mm | 1030 mm |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 743 mm | 758 mm | 767 mm | 789 mm | 808 mm | 819 mm | 834 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
