Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 PC | 50 PC | 52 PC | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $2,999 | $2,999 | $2,999 | $2,999 | $2,999 | $2,999 | $2,999 |
| Frame kit (g) | 1840 | 1840 | 1840 | 1840 | 1840 | 1840 | 1840 |
| Stack | 521 mm | 530 mm | 539 mm | 549 mm | 565 mm | 584 mm | 598 mm |
| Reach | 372 mm | 379 mm | 385 mm | 387 mm | 392 mm | 399 mm | 407 mm |
| Stack / Reach | 1.40 | 1.40 | 1.40 | 1.42 | 1.44 | 1.46 | 1.47 |
| Head tube angle | 71.3° | 72.5° | 73° | 73° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (effective) | 76.5° | 76° | 75.5° | 74° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 497 mm | 511 mm | 525 mm | 544 mm | 559 mm | 572 mm | 584 mm |
| Head tube length | 120 mm | 125 mm | 133 mm | 145 mm | 160 mm | 180 mm | 195 mm |
| Seat tube length | 460 mm | 465 mm | 475 mm | 485 mm | 500 mm | 520 mm | 535 mm |
| Bottom bracket drop | — | — | — | — | — | — | — |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 405 mm | 405 mm | 405 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Front center | — | — | — | — | — | — | — |
| Wheelbase | 969 mm | 968 mm | 973 mm | 984 mm | 988 mm | 1001 mm | 1013 mm |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 733 mm | 740 mm | 749 mm | 760 mm | 774 mm | 794 mm | 808 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
