Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 PC | 50 PC | 52 PC | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $1,650 | $1,650 | $1,650 | $1,650 | $1,650 | $1,650 | $1,650 |
| Frame kit (g) | 2130 | 2130 | 2130 | 2130 | 2130 | 2130 | 2130 |
| Stack | 526 mm | 537 mm | 552 mm | 563 mm | 577 mm | 601 mm | 621 mm |
| Reach | 376 mm | 381 mm | 388 mm | 394 mm | 399 mm | 405 mm | 415 mm |
| Stack / Reach | 1.40 | 1.41 | 1.42 | 1.43 | 1.45 | 1.48 | 1.50 |
| Head tube angle | 70.5° | 71° | 71.3° | 71.5° | 71.5° | 71.8° | 72° |
| Seat tube angle (effective) | 75.5° | 75° | 74.5° | 74° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 512 mm | 525 mm | 541 mm | 556 mm | 570 mm | 583 mm | 599 mm |
| Head tube length | 100 mm | 110 mm | 125 mm | 135 mm | 150 mm | 175 mm | 195 mm |
| Seat tube length | 460 mm | 470 mm | 485 mm | 495 mm | 510 mm | 535 mm | 555 mm |
| Bottom bracket drop | — | — | — | — | — | — | — |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Front center | — | — | — | — | — | — | — |
| Wheelbase | 1012 mm | 1017 mm | 1026 mm | 1034 mm | 1043 mm | 1054 mm | 1068 mm |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 750 mm | 760 mm | 774 mm | 784 mm | 798 mm | 822 mm | 842 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
