Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 PC | 50 PC | 52 PC | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $3,599 | $3,599 | $3,599 | $3,599 | $3,599 | $3,599 | $3,599 |
| Frame kit (g) | 2480 | 2480 | 2480 | 2480 | 2480 | 2480 | 2480 |
| Stack | 519 mm | 529 mm | 539 mm | 551 mm | 568 mm | 589 mm | 610 mm |
| Reach | 373 mm | 381 mm | 384 mm | 386 mm | 391 mm | 394 mm | 398 mm |
| Stack / Reach | 1.39 | 1.39 | 1.40 | 1.43 | 1.45 | 1.50 | 1.53 |
| Head tube angle | 71.3° | 71.3° | 71.5° | 71.5° | 72° | 72° | 72.5° |
| Seat tube angle (effective) | 76.5° | 75.5° | 75° | 74° | 73.5° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 500 mm | 520 mm | 530 mm | 545 mm | 560 mm | 575 mm | 585 mm |
| Head tube length | 89 mm | 100 mm | 110 mm | 122 mm | 138 mm | 160 mm | 180 mm |
| Seat tube length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Bottom bracket drop | — | — | — | — | — | — | — |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Front center | — | — | — | — | — | — | — |
| Wheelbase | 996 mm | 1008 mm | 1012 mm | 1018 mm | 1024 mm | 1034 mm | 1039 mm |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 746 mm | 760 mm | 774 mm | 789 mm | 805 mm | 826 mm | 846 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
