Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S | M | L | XL | |
|---|---|---|---|---|
| Price (CAD) | $6,300 | $6,300 | $6,300 | $6,300 |
| Frame kit (g) | 13900 | 13900 | 13900 | 13900 |
| Stack | 618 mm | 625 mm | 640 mm | 667 mm |
| Reach | 430 mm | 450 mm | 475 mm | 500 mm |
| Stack / Reach | 1.44 | 1.39 | 1.35 | 1.33 |
| Head tube angle | 66° | 66° | 66° | 66° |
| Seat tube angle (effective) | 74° | 74° | 74° | 73° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 665 mm | 700 mm | 607 mm | 632 mm |
| Head tube length | 131 mm | 139 mm | 155 mm | 185 mm |
| Seat tube length | 390 mm | 415 mm | 435 mm | 460 mm |
| Bottom bracket drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Bottom bracket height | 330 mm | 330 mm | 330 mm | 330 mm |
| Chainstay | 473 mm | 473 mm | 473 mm | 473 mm |
| Front center | 740 mm | 764 mm | 795 mm | 832 mm |
| Wheelbase | 1212 mm | 1235 mm | 1267 mm | 1304 mm |
| Fork rake (offset) | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork axle to crown | 531 mm | 531 mm | 531 mm | 531 mm |
| Trail | 112 mm | 112 mm | 112 mm | 112 mm |
| Standover | 747 mm | 747 mm | 747 mm | 747 mm |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
