Size S3
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S1 | S2 | S3 | S4 | S5 | |
|---|---|---|---|---|---|
| Price (CAD) | $2,050 | $2,050 | $2,050 | $2,050 | $2,050 |
| Frame kit (g) | 4550 | 4550 | 4550 | 4550 | 4550 |
| Stack | 605 mm | 609 mm | 618 mm | 627 mm | 636 mm |
| Reach | 415 mm | 440 mm | 465 mm | 490 mm | 515 mm |
| Stack / Reach | 1.46 | 1.38 | 1.33 | 1.28 | 1.24 |
| Head tube angle | 64° | 64° | 64° | 64° | 64° |
| Seat tube angle (effective) | 77° | 77° | 77° | 77° | 77° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 549 mm | 590 mm | 630 mm | 671 mm | 711 mm |
| Head tube length | 100 mm | 105 mm | 115 mm | 125 mm | 135 mm |
| Seat tube length | 390 mm | 400 mm | 420 mm | 440 mm | 465 mm |
| Bottom bracket drop | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Bottom bracket height | 338 mm | 338 mm | 338 mm | 338 mm | 338 mm |
| Chainstay | 427 mm | 427 mm | 427 mm | 432 mm | 432 mm |
| Front center | 741 mm | 768 mm | 798 mm | 827 mm | 857 mm |
| Wheelbase | 1168 mm | 1195 mm | 1225 mm | 1259 mm | 1288 mm |
| Fork rake (offset) | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork axle to crown | 551 mm | 551 mm | 551 mm | 551 mm | 551 mm |
| Trail | 134 mm | 134 mm | 134 mm | 134 mm | 134 mm |
| Standover | 735 mm | 735 mm | 739 mm | 743 mm | 747 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
