Size S
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XXS | XS | S | M | L | XL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $620 | $620 | $620 | $620 | $620 | $620 |
| Frame kit (g) | 2550 | 2550 | 2550 | 2550 | 2550 | 2550 |
| Stack | 536 mm | 555 mm | 563 mm | 593 mm | 608 mm | 633 mm |
| Reach | 373 mm | 388 mm | 393 mm | 398 mm | 402 mm | 414 mm |
| Stack / Reach | 1.44 | 1.43 | 1.43 | 1.49 | 1.51 | 1.53 |
| Head tube angle | 69.5° | 70° | 70° | 71° | 71° | 71° |
| Seat tube angle (effective) | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 532 mm | 552 mm | 560 mm | 574 mm | 582 mm | 602 mm |
| Head tube length | 121 mm | 139 mm | 147 mm | 175 mm | 191 mm | 217 mm |
| Seat tube length | 360 mm | 395 mm | 440 mm | 470 mm | 510 mm | 530 mm |
| Bottom bracket drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom bracket height | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm |
| Chainstay | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Front center | 606 mm | 623 mm | 631 mm | 636 mm | 645 mm | 665 mm |
| Wheelbase | 1036 mm | 1053 mm | 1061 mm | 1067 mm | 1076 mm | 1096 mm |
| Fork rake (offset) | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork axle to crown | 395 mm | 395 mm | 395 mm | 395 mm | 395 mm | 395 mm |
| Trail | 79 mm | 76 mm | 76 mm | 69 mm | 69 mm | 69 mm |
| Standover | 702 mm | 725 mm | 755 mm | 785 mm | 815 mm | 837 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
