Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
44 | 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $7,000 | $7,000 | $7,000 | $7,000 | $7,000 | $7,000 | $7,000 |
| Frame kit (g) | 2110 | 2110 | 2110 | 2110 | 2110 | 2110 | 2110 |
| Stack | 543 mm | 549 mm | 566 mm | 585 mm | 605 mm | 630 mm | 665 mm |
| Reach | 353 mm | 363 mm | 370 mm | 381 mm | 389 mm | 397 mm | 403 mm |
| Stack / Reach | 1.54 | 1.51 | 1.53 | 1.53 | 1.55 | 1.59 | 1.65 |
| Head tube angle | 69.3° | 70.8° | 71.5° | 72.3° | 73° | 73° | 73.5° |
| Seat tube angle (effective) | 75° | 74° | 74° | 74° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 503 mm | 523 mm | 534 mm | 550 mm | 569 mm | 584 mm | 600 mm |
| Head tube length | 90 mm | 90 mm | 105 mm | 122 mm | 140 mm | 168 mm | 202 mm |
| Seat tube length | 365 mm | 410 mm | 445 mm | 465 mm | 485 mm | 505 mm | 545 mm |
| Bottom bracket drop | 80 mm | 80 mm | 80 mm | 78 mm | 78 mm | 78 mm | 78 mm |
| Bottom bracket height | 269 mm | 269 mm | 269 mm | 270 mm | 270 mm | 271 mm | 271 mm |
| Chainstay | 418 mm | 418 mm | 418 mm | 420 mm | 420 mm | 423 mm | 423 mm |
| Front center | 593 mm | 598 mm | 604 mm | 620 mm | 631 mm | 589 mm | 587 mm |
| Wheelbase | 992 mm | 988 mm | 1005 mm | 1012 mm | 1031 mm | 1042 mm | 994 mm |
| Fork rake (offset) | 52 mm | 52 mm | 52 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Fork axle to crown | 375 mm | 375 mm | 375 mm | 375 mm | 375 mm | 375 mm | 375 mm |
| Trail | 76 mm | 66 mm | 62 mm | 61 mm | 57 mm | 57 mm | 54 mm |
| Standover | 686 mm | 719 mm | 747 mm | 766 mm | 787 mm | 809 mm | 847 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
