Specialized
A trail mountain bike frameset in 8 sizes, from XS-27.5 to XXL-29.
Frameset price, size S-29
$550
aggressive · rear-biased · snappy handling
From Specialized’s own numbers for the S-29, not marketing copy.
aggressive · rear-biased · snappy handling
From your saved height and inseam, not a height range.
Every size, straight from Specialized’s chart. Blanks are numbers Specialized doesn’t publish; we don’t fill them in.
| Measurement | ||||||||
|---|---|---|---|---|---|---|---|---|
| Stack (mm) | 559 | 573 | 589 | 607 | 616 | 626 | 640 | 654 |
| Reach (mm) | 375 | 395 | 415 | 405 | 425 | 445 | 465 | 485 |
| Stack / Reach | 1.49 | 1.45 | 1.42 | 1.50 | 1.45 | 1.41 | 1.38 | 1.35 |
| Head tube angle (°) | 68 | 68 | 68 | 68.5 | 68.5 | 68.5 | 68.5 | 68.5 |
| Seat tube angle (effective) (°) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Top tube (effective) (mm) | 541 | 565 | 589 | 586 | 608 | 630 | 654 | 679 |
| Chainstay (mm) | 440 | 440 | 440 | 440 | 440 | 440 | 440 | 440 |
| Wheelbase (mm) | 1067 | 1092 | 1118 | 1105 | 1128 | 1152 | 1178 | 1203 |
| Trail (mm) | 97 | 97 | 97 | 97 | 97 | 97 | 97 | 97 |
| Standover (mm) | 658 | 695 | 735 | 732 | 754 | 781 | 820 | 853 |
Specialized’s geometry chart, read Jul 21, 2026.
| Size | Frameset weight(g) | Price(CAD) |
|---|---|---|
| XS-27.5 | 3800 | $550 |
| S-27.5 | 3800 | $550 |
| M-27.5 | 3800 | $550 |
| S-29 | 3800 | $550 |
| M-29 | 3800 | $550 |
| L-29 | 3800 | $550 |
| XL-29 | 3800 | $550 |
| XXL-29 | 3800 | $550 |
Specialized · seat-wedge frames — Typical values from Specialized road user manuals (e.g. Roubaix / Aethos / Tarmac). Printed wedge / axle markings win when present.
| Bolt | Torque(Nm) | Torque(in·lb) | Tool |
|---|---|---|---|
| Seatpost wedge / binderCarbon paste per manual; do not grease carbon seat tube. | 6.2 | 54.9 | 4 mm hex |
| Front thru-axle | 15 | 132.8 | 6 mm hex |
| Rear thru-axle | 15 | 132.8 | 6 mm hex |
| Bottle cage | 2.8 | 24.8 | 3 mm hex |
| Derailleur hanger | 4.5 | 39.8 | 4 mm hex |
| Stem @ steerer (Future Stem / common)Confirm printed stem / bar specs when they disagree. | 5 | 44.3 | 4 mm hex |
Straight from Specialized’s own chart, read Jul 24, 2026. Anything printed on the part itself always wins.
