Size S2
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S1 | S2 | S3 | S4 | |
|---|---|---|---|---|
| Price (CAD) | $9,590 | $9,590 | $9,590 | $9,590 |
| Frame kit (g) | 3490 | 3490 | 3490 | 3490 |
| Stack | 594 mm | 604 mm | 618 mm | 645 mm |
| Reach | 420 mm | 450 mm | 480 mm | 505 mm |
| Stack / Reach | 1.41 | 1.34 | 1.29 | 1.28 |
| Head tube angle | 65.9° | 65.9° | 65.9° | 65.9° |
| Seat tube angle (effective) | 76° | 76° | 76° | 76° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 568 mm | 601 mm | 634 mm | 666 mm |
| Head tube length | 92 mm | 105 mm | 120 mm | 150 mm |
| Seat tube length | 390 mm | 410 mm | 455 mm | 505 mm |
| Bottom bracket drop | 42 mm | 40 mm | 40 mm | 40 mm |
| Bottom bracket height | 333 mm | 335 mm | 335 mm | 335 mm |
| Chainstay | 435 mm | 435 mm | 438 mm | 442 mm |
| Front center | 716 mm | 752 mm | 788 mm | 823 mm |
| Wheelbase | 1148 mm | 1184 mm | 1223 mm | 1264 mm |
| Fork rake (offset) | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork axle to crown | 531 mm | 531 mm | 531 mm | 531 mm |
| Trail | 120 mm | 120 mm | 120 mm | 120 mm |
| Standover | 749 mm | 755 mm | 757 mm | 764 mm |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
