Size S3
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S2 | S3 | S4 | S5 | |
|---|---|---|---|---|
| Price (CAD) | $4,110 | $4,110 | $4,110 | $4,110 |
| Frame kit (g) | 3820 | 3820 | 3820 | 3820 |
| Stack | 616 mm | 620 mm | 629 mm | 638 mm |
| Reach | 437 mm | 464 mm | 487 mm | 511 mm |
| Stack / Reach | 1.41 | 1.34 | 1.29 | 1.25 |
| Head tube angle | 63.9° | 63.9° | 63.9° | 63.9° |
| Seat tube angle (effective) | 76° | 76° | 76° | 76° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 591 mm | 619 mm | 644 mm | 670 mm |
| Head tube length | 95 mm | 100 mm | 110 mm | 120 mm |
| Seat tube length | 400 mm | 420 mm | 440 mm | 465 mm |
| Bottom bracket drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Bottom bracket height | 347 mm | 347 mm | 347 mm | 347 mm |
| Chainstay | 442 mm | 442 mm | 442 mm | 442 mm |
| Front center | 777 mm | 806 mm | 833 mm | 862 mm |
| Wheelbase | 1217 mm | 1246 mm | 1274 mm | 1302 mm |
| Fork rake (offset) | 46 mm | 46 mm | 46 mm | 46 mm |
| Fork axle to crown | 581 mm | 581 mm | 581 mm | 581 mm |
| Trail | 132 mm | 132 mm | 132 mm | 132 mm |
| Standover | — | — | — | — |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
