Size S4
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S3 | S4 | S5 | |
|---|---|---|---|
| Price (CAD) | $8,905 | $8,905 | $8,905 |
| Frame kit (g) | 5790 | 5790 | 5790 |
| Stack | 645 mm | 645 mm | 645 mm |
| Reach | 445 mm | 475 mm | 500 mm |
| Stack / Reach | 1.45 | 1.36 | 1.29 |
| Head tube angle | 62.5° | 62.5° | 62.5° |
| Seat tube angle (effective) | 78° | 78° | 78° |
| Seat tube angle (actual) | — | — | — |
| Top tube (effective) | 582 mm | 614 mm | 637 mm |
| Head tube length | 110 mm | 110 mm | 110 mm |
| Seat tube length | 400 mm | 420 mm | 420 mm |
| Bottom bracket drop | 20 mm | 20 mm | 20 mm |
| Bottom bracket height | 348 mm | 348 mm | 348 mm |
| Chainstay | 435 mm | 445 mm | 455 mm |
| Front center | 825 mm | 857 mm | 880 mm |
| Wheelbase | 1260 mm | 1302 mm | 1335 mm |
| Fork rake (offset) | 52 mm | 52 mm | 52 mm |
| Fork axle to crown | 611 mm | 611 mm | 611 mm |
| Trail | 137 mm | 137 mm | 137 mm |
| Standover | — | — | — |
| Pad / effective stack | — | — | — |
| Pad / effective reach | — | — | — |
