Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Price (CAD) | $1,370 | $1,370 | $1,370 | $1,370 | $1,370 |
| Frame kit (g) | 1960 | 1960 | 1960 | 1960 | 1960 |
| Stack | 591 mm | 605 mm | 605 mm | 619 mm | 633 mm |
| Reach | 385 mm | 405 mm | 430 mm | 455 mm | 480 mm |
| Stack / Reach | 1.53 | 1.49 | 1.41 | 1.36 | 1.32 |
| Head tube angle | 68° | 68° | 68° | 68° | 68° |
| Seat tube angle (effective) | 74° | 74° | 74° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 555 mm | 578 mm | 603 mm | 632 mm | 661 mm |
| Head tube length | 95 mm | 95 mm | 95 mm | 110 mm | 125 mm |
| Seat tube length | 367 mm | 400 mm | 430 mm | 470 mm | 520 mm |
| Bottom bracket drop | 68 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Bottom bracket height | 304 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Chainstay | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Front center | 647 mm | 674 mm | 699 mm | 730 mm | 760 mm |
| Wheelbase | 1070 mm | 1099 mm | 1124 mm | 1154 mm | 1185 mm |
| Fork rake (offset) | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork axle to crown | 486 mm | 506 mm | 506 mm | 506 mm | 506 mm |
| Trail | 103 mm | 103 mm | 103 mm | 103 mm | 103 mm |
| Standover | 732 mm | 762 mm | 792 mm | 816 mm | 847 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
