Salsa
A gravel frameset in 7 sizes, from 49 to 61.
Frameset price, size 56
Not published
endurance · rear-biased · neutral handling
From Salsa’s own numbers for the 56, not marketing copy.
endurance · rear-biased · neutral handling
From your saved height and inseam, not a height range.
Every size, straight from Salsa’s chart. Blanks are numbers Salsa doesn’t publish; we don’t fill them in.
| Measurement | |||||||
|---|---|---|---|---|---|---|---|
| Stack (mm) | 517.9 | 547.1 | 566.0 | 584.9 | 603.7 | 622.6 | 641.5 |
| Reach (mm) | 360.2 | 368.1 | 372.0 | 381.2 | 390.4 | 399.6 | 407.7 |
| Stack / Reach | 1.44 | 1.49 | 1.52 | 1.53 | 1.55 | 1.56 | 1.57 |
| Head tube angle (°) | 71 | 70.8 | 70.8 | 70.8 | 70.8 | 70.8 | 70.8 |
| Seat tube angle (effective) (°) | 75 | 74 | 73 | 73 | 73 | 73 | 72.5 |
| Top tube (effective) (mm) | 499 | 525 | 545 | 560 | 575 | 590 | 610 |
| Chainstay (mm) | 430 | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbase (mm) | 996.1 | 1012.0 | 1022.4 | 1038.2 | 1054.0 | 1069.8 | 1084.5 |
| Trail (mm) | Not published | Not published | Not published | Not published | Not published | Not published | Not published |
| Standover (mm) | 670.2 | 714.5 | 744.3 | 770.1 | 786.0 | 808.4 | 830.5 |
Salsa’s geometry chart, read Aug 3, 2026.
Salsa hasn’t published frame bolt torques we can point to yet
