Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Price (CAD) | $958 | $958 | $958 | $958 | $958 |
| Frame kit (g) | 2495 | 2495 | 2495 | 2495 | 2495 |
| Stack | 599 mm | 599 mm | 607.4 mm | 613.5 mm | 625.5 mm |
| Reach | 410.7 mm | 433.6 mm | 453.6 mm | 475.5 mm | 492.6 mm |
| Stack / Reach | 1.46 | 1.38 | 1.34 | 1.29 | 1.27 |
| Head tube angle | 66.4° | 66.4° | 66.4° | 66.4° | 66.4° |
| Seat tube angle (effective) | 75.1° | 75.1° | 75.1° | 75.1° | 75.1° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 570 mm | 594.1 mm | 615.3 mm | 639 mm | 659.3 mm |
| Head tube length | 100 mm | 100 mm | 105 mm | 115 mm | 125 mm |
| Seat tube length | 342.9 mm | 370 mm | 395 mm | 432 mm | 457.2 mm |
| Bottom bracket drop | 56.6 mm | 56.6 mm | 56.6 mm | 56.6 mm | 56.6 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Front center | — | — | — | — | — |
| Wheelbase | 1137 mm | 1159.5 mm | 1181.5 mm | 1197.5 mm | 1228.7 mm |
| Fork rake (offset) | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Fork axle to crown | 543 mm | 543 mm | 543 mm | 543 mm | 543 mm |
| Trail | — | — | — | — | — |
| Standover | 702.9 mm | 722.6 mm | 742.1 mm | 772.1 mm | 792.9 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
