Salsa
A cross-country mountain bike frameset in 4 sizes, from S to XL.
Frameset price, size M
$1,780
endurance · neutral handling
From Salsa’s own numbers for the M, not marketing copy.
endurance · neutral handling
From your saved height and inseam, not a height range.
Every size, straight from Salsa’s chart. Blanks are numbers Salsa doesn’t publish; we don’t fill them in.
| Measurement | ||||
|---|---|---|---|---|
| Stack (mm) | 609 | 618 | 627 | 636.5 |
| Reach (mm) | 423 | 442 | 461 | 480 |
| Stack / Reach | 1.44 | 1.40 | 1.36 | 1.33 |
| Head tube angle (°) | 67.9 | 67.9 | 67.9 | 67.9 |
| Seat tube angle (effective) (°) | 74.4 | 74.4 | 74.4 | 74.4 |
| Top tube (effective) (mm) | 592.5 | 614.5 | 636 | 657.5 |
| Chainstay (mm) | 431.5 | 431.5 | 431.5 | 431.5 |
| Wheelbase (mm) | 1131 | 1154 | 1176 | 1199 |
| Trail (mm) | 100.3 | 100.3 | 100.3 | 100.3 |
| Standover (mm) | 734.5 | 745 | 756.5 | 766.5 |
Salsa’s geometry chart, read Jul 21, 2026.
| Size | Frameset weight(g) | Price(CAD) |
|---|---|---|
| S | 2880 | $1,780 |
| M | 2880 | $1,780 |
| L | 2880 | $1,780 |
| XL | 2880 | $1,780 |
Salsa hasn’t published frame bolt torques we can point to yet
