Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS | S | M | M/L | L | XL | |
|---|---|---|---|---|---|---|
| Price (CAD) | $3,835 | $3,835 | $3,835 | $3,835 | $3,835 | $3,835 |
| Frame kit (g) | 1650 | 1650 | 1650 | 1650 | 1650 | 1650 |
| Stack | 540.5 mm | 549.9 mm | 568.8 mm | 592.3 mm | 625.3 mm | 644.2 mm |
| Reach | 375.2 mm | 387.7 mm | 391.9 mm | 405.2 mm | 420.7 mm | 435.3 mm |
| Stack / Reach | 1.44 | 1.42 | 1.45 | 1.46 | 1.49 | 1.48 |
| Head tube angle | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| Seat tube angle (effective) | 76° | 75° | 74° | 74° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 510 mm | 535 mm | 555 mm | 575 mm | 600 mm | 620 mm |
| Head tube length | 90 mm | 100 mm | 120 mm | 145 mm | 180 mm | 200 mm |
| Seat tube length | 390 mm | 430 mm | 470 mm | 505 mm | 540 mm | 575 mm |
| Bottom bracket drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Bottom bracket height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Chainstay | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Front center | — | — | — | — | — | — |
| Wheelbase | 1012 mm | 1027.7 mm | 1038.7 mm | 1060.2 mm | 1087.5 mm | 1108.7 mm |
| Fork rake (offset) | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork axle to crown | 419.9 mm | 419.9 mm | 419.9 mm | 419.9 mm | 419.9 mm | 419.9 mm |
| Trail | — | — | — | — | — | — |
| Standover | 682 mm | 715 mm | 749 mm | 780 mm | 814 mm | 843 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
