Size 56
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|
| Price (CAD) | $3,561 | $3,561 | $3,561 | $3,561 | $3,561 |
| Frame kit (g) | 2353 | 2353 | 2353 | 2353 | 2353 |
| Stack | 585 mm | 592 mm | 620 mm | 645 mm | 664 mm |
| Reach | 357 mm | 372 mm | 385 mm | 394 mm | 406 mm |
| Stack / Reach | 1.64 | 1.59 | 1.61 | 1.64 | 1.64 |
| Head tube angle | 69° | 69° | 69° | 69° | 69° |
| Seat tube angle (effective) | 74.5° | 74.3° | 74.3° | 74° | 73.8° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head tube length | 90 mm | 98 mm | 127 mm | 154 mm | 175 mm |
| Seat tube length | 356 mm | 419 mm | 508 mm | 559 mm | 584 mm |
| Bottom bracket drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom bracket height | 300 mm | 300 mm | 300 mm | 300 mm | 300 mm |
| Chainstay | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Front center | — | — | — | — | — |
| Wheelbase | 1050 mm | 1066 mm | 1091 mm | 1110 mm | 1129 mm |
| Fork rake (offset) | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork axle to crown | 483 mm | 483 mm | 483 mm | 483 mm | 483 mm |
| Trail | — | — | — | — | — |
| Standover | 700 mm | 742 mm | 811 mm | 852 mm | 874 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
