Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S | M | L | XL | |
|---|---|---|---|---|
| Price (CAD) | $5,068 | $5,068 | $5,068 | $5,068 |
| Frame kit (g) | 3090 | 3090 | 3090 | 3090 |
| Stack | 613.5 mm | 622.5 mm | 631.5 mm | 640.5 mm |
| Reach | 450.5 mm | 470.5 mm | 490.5 mm | 510.5 mm |
| Stack / Reach | 1.36 | 1.32 | 1.29 | 1.25 |
| Head tube angle | 63.8° | 63.8° | 63.8° | 63.8° |
| Seat tube angle (effective) | 77.2° | 77.2° | 77.2° | 77.2° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 589.5 mm | 611.5 mm | 633.5 mm | 655.5 mm |
| Head tube length | 100 mm | 110 mm | 120 mm | 130 mm |
| Seat tube length | 405 mm | 430 mm | 455 mm | 480 mm |
| Bottom bracket drop | 27.5 mm | 27.5 mm | 27.5 mm | 27.5 mm |
| Bottom bracket height | 348.5 mm | 348.5 mm | 348.5 mm | 348.5 mm |
| Chainstay | 432.5 mm | 432.5 mm | 432.5 mm | 432.5 mm |
| Front center | — | — | — | — |
| Wheelbase | 1219.5 mm | 1243.5 mm | 1268.5 mm | 1292.5 mm |
| Fork rake (offset) | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | 571 mm | 571 mm | 571 mm | 571 mm |
| Trail | — | — | — | — |
| Standover | 744.5 mm | 744.5 mm | 745 mm | 745 mm |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
