Size M
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
S | M | L | XL | |
|---|---|---|---|---|
| Price (CAD) | $5,070 | $5,070 | $5,070 | $5,070 |
| Frame kit (g) | 3000 | 3000 | 3000 | 3000 |
| Stack | 607 mm | 615.5 mm | 624.5 mm | 633.5 mm |
| Reach | 460 mm | 480 mm | 500 mm | 519.5 mm |
| Stack / Reach | 1.32 | 1.28 | 1.25 | 1.22 |
| Head tube angle | 64.6° | 64.6° | 64.6° | 64.6° |
| Seat tube angle (effective) | 78.1° | 78.1° | 78.1° | 78.1° |
| Seat tube angle (actual) | — | — | — | — |
| Top tube (effective) | 587.5 mm | 609.5 mm | 631.5 mm | 653.5 mm |
| Head tube length | 100 mm | 110 mm | 120 mm | 130 mm |
| Seat tube length | 405 mm | 430 mm | 455 mm | 480 mm |
| Bottom bracket drop | 34 mm | 33.5 mm | 33.5 mm | 33.5 mm |
| Bottom bracket height | 342 mm | 342.5 mm | 342.5 mm | 342.5 mm |
| Chainstay | 432.5 mm | 432.5 mm | 432.5 mm | 432.5 mm |
| Front center | — | — | — | — |
| Wheelbase | 1210.5 mm | 1235.5 mm | 1260 mm | 1283.5 mm |
| Fork rake (offset) | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | 551 mm | 551 mm | 551 mm | 551 mm |
| Trail | — | — | — | — |
| Standover | 734.5 mm | 734.5 mm | 735 mm | 735 mm |
| Pad / effective stack | — | — | — | — |
| Pad / effective reach | — | — | — | — |
