Size S/555
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XXS/455 | XS/498 | S/555 | M/560 | L/565 | |
|---|---|---|---|---|---|
| Price (CAD) | $3,698 | $3,698 | $3,698 | $3,698 | $3,698 |
| Frame kit (g) | 1688 | 1688 | 1688 | 1688 | 1688 |
| Stack | 481 mm | 486 mm | 494 mm | 499 mm | 503 mm |
| Reach | 375 mm | 378 mm | 390 mm | 405 mm | 420 mm |
| Stack / Reach | 1.28 | 1.29 | 1.27 | 1.23 | 1.20 |
| Head tube angle | 71° | 71° | 72° | 72° | 72° |
| Seat tube angle (effective) | 75° | 75° | 75° | 75° | 75° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 504 mm | 508 mm | 522 mm | 538 mm | 555 mm |
| Head tube length | 80 mm | 85 mm | 90 mm | 95 mm | 100 mm |
| Seat tube length | 455 mm | 498 mm | 555 mm | 560 mm | 565 mm |
| Bottom bracket drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Front center | 569.9 mm | 574.8 mm | 581.8 mm | 597.6 mm | 614.5 mm |
| Wheelbase | 968 mm | 973 mm | 980 mm | 996 mm | 1013 mm |
| Fork rake (offset) | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Fork axle to crown | 365 mm | 365 mm | 365 mm | 365 mm | 365 mm |
| Trail | — | — | — | — | — |
| Standover | 735 mm | 760 mm | 802 mm | 808 mm | 814 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
