Size M/486
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS/426 | S/456 | M/486 | L/516 | XL/546 | |
|---|---|---|---|---|---|
| Price (CAD) | $2,684 | $2,684 | $2,684 | $2,684 | $2,684 |
| Frame kit (g) | 1558 | 1558 | 1558 | 1558 | 1558 |
| Stack | 524 mm | 543 mm | 561 mm | 580 mm | 599 mm |
| Reach | 370 mm | 379 mm | 388 mm | 398 mm | 405 mm |
| Stack / Reach | 1.42 | 1.43 | 1.45 | 1.46 | 1.48 |
| Head tube angle | 70.5° | 71° | 71° | 71° | 71° |
| Seat tube angle (effective) | 74.2° | 74° | 73.6° | 73.3° | 73.8° |
| Seat tube angle (actual) | — | — | — | — | — |
| Top tube (effective) | 518 mm | 535 mm | 553 mm | 572 mm | 590 mm |
| Head tube length | 95 mm | 113 mm | 132 mm | 152 mm | 172 mm |
| Seat tube length | — | — | — | — | 546 mm |
| Bottom bracket drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Bottom bracket height | — | — | — | — | — |
| Chainstay | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Front center | — | — | — | — | 648 mm |
| Wheelbase | 1006 mm | 1016 mm | 1032 mm | 1048 mm | 1062 mm |
| Fork rake (offset) | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Fork axle to crown | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Trail | — | — | — | — | — |
| Standover | 723 mm | 742 mm | 760 mm | 779 mm | 798 mm |
| Pad / effective stack | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — |
