Size M/490
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
XS/430 | S/460 | M/490 | L/520 | XL/550 | XXL/580 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $2,602 | $2,602 | $2,602 | $2,602 | $2,602 | $2,602 |
| Frame kit (g) | 1310 | 1310 | 1310 | 1310 | 1310 | 1310 |
| Stack | 503.9 mm | 516.7 mm | 534.6 mm | 552 mm | 566.6 mm | 587.7 mm |
| Reach | 375.4 mm | 382.2 mm | 386.7 mm | 391.4 mm | 402 mm | 412.3 mm |
| Stack / Reach | 1.34 | 1.35 | 1.38 | 1.41 | 1.41 | 1.43 |
| Head tube angle | 70° | 71° | 72° | 73° | 73° | 73° |
| Seat tube angle (effective) | 75° | 74.5° | 74° | 73.5° | 73.5° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 510 mm | 525 mm | 540 mm | 555 mm | 570 mm | 589 mm |
| Head tube length | 105 mm | 115 mm | 130 mm | 145 mm | 160 mm | 180 mm |
| Seat tube length | 430 mm | 460 mm | 490 mm | 520 mm | — | — |
| Bottom bracket drop | 71.7 mm | 71.7 mm | 71.7 mm | 71.7 mm | 71.7 mm | 71.7 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Front center | 584.7 mm | 587.2 mm | 588.7 mm | 589.7 mm | — | — |
| Wheelbase | 982 mm | 984.5 mm | 986 mm | 987 mm | 1002 mm | 1013.7 mm |
| Fork rake (offset) | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Fork axle to crown | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm |
| Trail | — | — | — | — | — | — |
| Standover | 710.5 mm | 736 mm | 761.5 mm | 787 mm | 812.5 mm | 837 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
