Size 56
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
49 | 52 | 54 | 56 | 58 | 60 | 62 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $17,120 | $17,120 | $17,120 | $17,120 | $17,120 | $17,120 | $17,120 |
| Frame kit (g) | 2200 | 2200 | 2200 | 2200 | 2200 | 2200 | 2200 |
| Stack | 517 mm | 536 mm | 555 mm | 575 mm | 596 mm | 618 mm | 639 mm |
| Reach | 375 mm | 381 mm | 393 mm | 399 mm | 405 mm | 410 mm | 425 mm |
| Stack / Reach | 1.38 | 1.41 | 1.41 | 1.44 | 1.47 | 1.51 | 1.50 |
| Head tube angle | 71.8° | 72° | 73° | 73° | 73° | 73° | 73.3° |
| Seat tube angle (effective) | 75.5° | 75° | 74.8° | 74.5° | 74.3° | 74° | 73.8° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 510 mm | 526 mm | 545 mm | 559 mm | 573 mm | 593 mm | 611 mm |
| Head tube length | 115 mm | 134 mm | 150 mm | 171 mm | 193 mm | 219 mm | 239 mm |
| Seat tube length | 445 mm | 470 mm | 500 mm | 510 mm | 515 mm | 525 mm | 535 mm |
| Bottom bracket drop | 76 mm | 76 mm | 75 mm | 74 mm | 74 mm | 72 mm | 72 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 407 mm | 407 mm | 410 mm | 410 mm | 410 mm | 410 mm | 412 mm |
| Front center | 578 mm | 588 mm | 592 mm | 604 mm | 616 mm | 633 mm | 647 mm |
| Wheelbase | 973 mm | 983 mm | 990 mm | 1003 mm | 1015 mm | 1033 mm | 1048 mm |
| Fork rake (offset) | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | 60 mm | 59 mm | 58 mm | 58 mm | 58 mm | 58 mm | 56 mm |
| Standover | 746 mm | 767 mm | 792 mm | 807 mm | 820 mm | 838 mm | 853 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
