Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $8,904 | $8,904 | $8,904 | $8,904 | $8,904 | $8,904 | $8,904 |
| Frame kit (g) | 1950 | 1950 | 1950 | 1950 | 1950 | 1950 | 1950 |
| Stack | 501 mm | 503 mm | 522 mm | 545 mm | 564 mm | 590 mm | 609 mm |
| Reach | 369 mm | 374 mm | 379 mm | 388 mm | 395 mm | 400 mm | 409 mm |
| Stack / Reach | 1.36 | 1.34 | 1.38 | 1.41 | 1.43 | 1.48 | 1.49 |
| Head tube angle | 71.5° | 72° | 72° | 72.8° | 73.2° | 73.2° | 73.2° |
| Seat tube angle (effective) | 75° | 74.5° | 74° | 74° | 73.2° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 505 mm | 515 mm | 530 mm | 545 mm | 565 mm | 580 mm | 595 mm |
| Head tube length | 100 mm | 100 mm | 120 mm | 140 mm | 160 mm | 190 mm | 210 mm |
| Seat tube length | 440 mm | 456 mm | 475 mm | 496 mm | 514 mm | 545 mm | 568 mm |
| Bottom bracket drop | 72 mm | 72 mm | 72 mm | 72 mm | 70 mm | 68 mm | 68 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 410 mm | 410 mm | 410 mm | 412 mm | 412 mm | 415 mm | 415 mm |
| Front center | 569 mm | 571 mm | 582 mm | 586 mm | 595 mm | 608 mm | 623 mm |
| Wheelbase | — | — | — | — | — | — | — |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 731 mm | 739 mm | 757 mm | 779 mm | 800 mm | 829 mm | 850 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
