Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $5,890 | $5,890 | $5,890 | $5,890 | $5,890 | $5,890 |
| Frame kit (g) | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 |
| Stack | 504 mm | 523 mm | 542 mm | 561 mm | 580 mm | 600 mm |
| Reach | 383 mm | 384 mm | 389 mm | 398 mm | 408 mm | 418 mm |
| Stack / Reach | 1.32 | 1.36 | 1.39 | 1.41 | 1.42 | 1.44 |
| Head tube angle | 73° | 73° | 73° | 73° | 73° | 73° |
| Seat tube angle (effective) | 75.5° | 75° | 74.5° | 74.5° | 74° | 74° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 515 mm | 525 mm | 540 mm | 555 mm | 575 mm | 590 mm |
| Head tube length | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Seat tube length | 475 mm | 495 mm | 520 mm | 540 mm | 565 mm | 585 mm |
| Bottom bracket drop | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Bottom bracket height | — | — | — | — | — | — |
| Chainstay | 393 mm | 393 mm | 393 mm | 396 mm | 396 mm | 396 mm |
| Front center | 569 mm | 576 mm | 587 mm | 602 mm | 617 mm | 633 mm |
| Wheelbase | — | — | — | — | — | — |
| Fork rake (offset) | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — |
| Standover | 761 mm | 781 mm | 802 mm | 821 mm | 842 mm | 864 mm |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
