Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $7,534 | $7,534 | $7,534 | $7,534 | $7,534 | $7,534 | $7,534 |
| Frame kit (g) | 2050 | 2050 | 2050 | 2050 | 2050 | 2050 | 2050 |
| Stack | 504 mm | 516 mm | 537 mm | 561 mm | 577 mm | 595 mm | 615 mm |
| Reach | 357 mm | 365 mm | 369 mm | 378 mm | 383 mm | 398 mm | 407 mm |
| Stack / Reach | 1.41 | 1.41 | 1.46 | 1.48 | 1.51 | 1.50 | 1.51 |
| Head tube angle | 70.5° | 71° | 71.2° | 72.2° | 72.5° | 73° | 73° |
| Seat tube angle (effective) | 75° | 74.5° | 74° | 73.5° | 73° | 73° | 72.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 496 mm | 510 mm | 525 mm | 545 mm | 560 mm | 580 mm | 600 mm |
| Head tube length | 100 mm | 110 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Seat tube length | 445 mm | 462 mm | 490 mm | 518 mm | 540 mm | 565 mm | 590 mm |
| Bottom bracket drop | 78 mm | 78 mm | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 412 mm | 412 mm | 412 mm | 415 mm | 415 mm | 415 mm | 418 mm |
| Front center | 567 mm | 574 mm | 584 mm | 586 mm | 594 mm | 609 mm | 623 mm |
| Wheelbase | — | — | — | — | — | — | — |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 727 mm | 740 mm | 767 mm | 792 mm | 810 mm | 833 mm | 854 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
