Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $9,041 | $9,041 | $9,041 | $9,041 | $9,041 | $9,041 | $9,041 |
| Frame kit (g) | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 |
| Stack | 523 mm | 533 mm | 549 mm | 566 mm | 580 mm | 600 mm | 620 mm |
| Reach | 359 mm | 365 mm | 371 mm | 381 mm | 386 mm | 395 mm | 405 mm |
| Stack / Reach | 1.46 | 1.46 | 1.48 | 1.49 | 1.50 | 1.52 | 1.53 |
| Head tube angle | 70.2° | 70.5° | 70.5° | 71° | 71.2° | 71.2° | 71.5° |
| Seat tube angle (effective) | 75° | 74.5° | 74.5° | 74° | 73.5° | 73.5° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 502 mm | 515 mm | 525 mm | 545 mm | 560 mm | 575 mm | 595 mm |
| Head tube length | 110 mm | 120 mm | 135 mm | 155 mm | 170 mm | 190 mm | 210 mm |
| Seat tube length | 440 mm | 458 mm | 482 mm | 505 mm | 520 mm | 535 mm | 560 mm |
| Bottom bracket drop | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm | 73 mm | 72 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 423 mm | 423 mm | 425 mm | 425 mm | 427 mm | 427 mm | 428 mm |
| Front center | 579 mm | 585 mm | 593 mm | 608 mm | 616 mm | 632 mm | 645 mm |
| Wheelbase | — | — | — | — | — | — | — |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 752 mm | 766 mm | 785 mm | 806 mm | 820 mm | 837 mm | 859 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
