Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
48 | 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $8,904 | $8,904 | $8,904 | $8,904 | $8,904 | $8,904 | $8,904 |
| Frame kit (g) | 2140 | 2140 | 2140 | 2140 | 2140 | 2140 | 2140 |
| Stack | 565 mm | 574 mm | 584 mm | 590 mm | 606 mm | 627 mm | 641 mm |
| Reach | 366 mm | 368 mm | 375 mm | 383 mm | 394 mm | 404 mm | 403 mm |
| Stack / Reach | 1.54 | 1.56 | 1.56 | 1.54 | 1.54 | 1.55 | 1.59 |
| Head tube angle | 69.5° | 69.5° | 69.5° | 69.5° | 70° | 70.5° | 70.5° |
| Seat tube angle (effective) | 75.5° | 75° | 75° | 74.5° | 74° | 74° | 73.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 515 mm | 525 mm | 535 mm | 550 mm | 570 mm | 580 mm | 595 mm |
| Head tube length | 100 mm | 110 mm | 120 mm | 130 mm | 145 mm | 165 mm | 180 mm |
| Seat tube length | 420 mm | 440 mm | 470 mm | 485 mm | 505 mm | 525 mm | 545 mm |
| Bottom bracket drop | 83 mm | 83 mm | 83 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 440 mm | 440 mm | 440 mm | 440 mm | 442 mm | 442 mm | 443 mm |
| Front center | 602 mm | 607 mm | 618 mm | 629 mm | 640 mm | 652 mm | 657 mm |
| Wheelbase | — | — | — | — | — | — | — |
| Fork rake (offset) | — | — | — | — | — | — | — |
| Fork axle to crown | — | — | — | — | — | — | — |
| Trail | — | — | — | — | — | — | — |
| Standover | 770 mm | 784 mm | 803 mm | 816 mm | 833 mm | 854 mm | 869 mm |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
