Size 52
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
46 | 49 | 52 | 54 | 56 | 58 | |
|---|---|---|---|---|---|---|
| Price (CAD) | $1,230 | $1,230 | $1,230 | $1,230 | $1,230 | $1,230 |
| Frame kit (g) | 1543 | 1543 | 1543 | 1543 | 1543 | 1543 |
| Stack | 505 mm | 519 mm | 544 mm | 565 mm | 590 mm | 610 mm |
| Reach | 365 mm | 374 mm | 378 mm | 387 mm | 398 mm | 406 mm |
| Stack / Reach | 1.38 | 1.39 | 1.44 | 1.46 | 1.48 | 1.50 |
| Head tube angle | 70° | 70° | 70° | 71° | 71° | 71° |
| Seat tube angle (effective) | 74.5° | 74.5° | 74° | 73.5° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — |
| Top tube (effective) | 505 mm | 518 mm | 534.5 mm | 554.5 mm | 578.5 mm | 592.5 mm |
| Head tube length | 79 mm | 94 mm | 121 mm | 139 mm | 165 mm | 186 mm |
| Seat tube length | 460 mm | 475 mm | 490 mm | 505 mm | 523 mm | 543 mm |
| Bottom bracket drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Bottom bracket height | 288.5 mm | 288.5 mm | 288.5 mm | 288.5 mm | 288.5 mm | 288.5 mm |
| Chainstay | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Front center | 580 mm | 595 mm | 608 mm | 614 mm | 634 mm | 648 mm |
| Wheelbase | 995 mm | 1009 mm | 1023 mm | 1029 mm | 1049 mm | 1064 mm |
| Fork rake (offset) | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Fork axle to crown | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Trail | — | — | — | — | — | — |
| Standover | — | — | — | — | — | — |
| Pad / effective stack | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — |
