ENVE
A gravel frameset in 6 sizes, from 49 to 60.
Frameset price, size 54
$9,589
aggressive · snappy handling
From ENVE’s own numbers for the 54, not marketing copy.
aggressive · snappy handling
From your saved height and inseam, not a height range.
Every size, straight from ENVE’s chart. Blanks are numbers ENVE doesn’t publish; we don’t fill them in.
| Measurement | ||||||
|---|---|---|---|---|---|---|
| Stack (mm) | 520 | 543 | 565 | 587 | 605 | 630 |
| Reach (mm) | 367 | 378 | 389 | 397 | 405 | 415 |
| Stack / Reach | 1.42 | 1.44 | 1.45 | 1.48 | 1.49 | 1.52 |
| Head tube angle (°) | 71 | 71 | 71.3 | 71.3 | 71.5 | 71.5 |
| Seat tube angle (effective) (°) | 74.5 | 74 | 73.8 | 73.5 | 73.2 | 72.8 |
| Top tube (effective) (mm) | 511 | 534 | 554 | 571 | 588 | 611 |
| Chainstay (mm) | 420 | 420 | 420 | 420 | 420 | 420 |
| Wheelbase (mm) | 993 | 1012 | 1027 | 1042 | 1053 | 1071 |
| Trail (mm) | 61.4 | 61.4 | 61.9 | 61.9 | 62.4 | 62.4 |
| Standover (mm) | 702 | 722 | 744 | 764 | 784 | 807 |
ENVE’s geometry chart, read Aug 3, 2026.
| Size | Frameset weight(g) | Price(CAD) |
|---|---|---|
| 49 | Not published | $9,589 |
| 52 | Not published | $9,589 |
| 54 | Not published | $9,589 |
| 56 | Not published | $9,589 |
| 58 | Not published | $8,904 |
| 60 | Not published |
| $8,904 |
ENVE hasn’t published frame bolt torques we can point to yet
