Size 510
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
420 | 455 | 485 | 510 | 530 | 550 | 570 | |
|---|---|---|---|---|---|---|---|
| Price (CAD) | $9,248 | $9,248 | $9,248 | $9,248 | $9,248 | $9,248 | $9,248 |
| Frame kit (g) | 1490 | 1490 | 1490 | 1490 | 1490 | 1490 | 1490 |
| Stack | 510 mm | 522 mm | 539 mm | 557 mm | 575 mm | 593 mm | 612 mm |
| Reach | 370 mm | 375 mm | 383 mm | 388 mm | 395 mm | 403 mm | 410 mm |
| Stack / Reach | 1.38 | 1.39 | 1.41 | 1.44 | 1.46 | 1.47 | 1.49 |
| Head tube angle | 70.6° | 71° | 71.5° | 71.8° | 72.5° | 72.9° | 73.1° |
| Seat tube angle (effective) | 75.5° | 75° | 74.5° | 74° | 73.5° | 73° | 73° |
| Seat tube angle (actual) | — | — | — | — | — | — | — |
| Top tube (effective) | 504 mm | 517 mm | 535 mm | 550 mm | 567 mm | 586 mm | 599 mm |
| Head tube length | 103 mm | 114 mm | 130 mm | 148 mm | 164 mm | 181 mm | 200 mm |
| Seat tube length | 420 mm | 455 mm | 485 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Bottom bracket drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Bottom bracket height | — | — | — | — | — | — | — |
| Chainstay | 408 mm | 408 mm | 408 mm | 410 mm | 414 mm | 414 mm | 414 mm |
| Front center | 576 mm | 582 mm | 591 mm | 599 mm | 605 mm | 614.5 mm | 625 mm |
| Wheelbase | 973.1 mm | 979.1 mm | 988.2 mm | 998.3 mm | 1008.4 mm | 1018 mm | 1028.5 mm |
| Fork rake (offset) | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Fork axle to crown | 379 mm | 379 mm | 379 mm | 379 mm | 379 mm | 379 mm | 379 mm |
| Trail | — | — | — | — | — | — | — |
| Standover | — | — | — | — | — | — | — |
| Pad / effective stack | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — |
